Ingress Protection

 IP66 / 67

 Junction Box Material

 Glass Fibre Reinforced Polyester(GRP)

 Gasket Material

 Silicon Rubber

 Mounting

 Integral 6mm clearance holes moulded into the body

 Earthing

 Optional M8 internal/external earth stud, brass or stainless steel

 UV Protection

 1000hr (IEC 60079-0 26.10)

 Impact Resistance

 7Nm(EN50014)

 Color

 RAL 9005 Black

 RAL 7001 Gray(option-BMC material)

 RAL 3001 Gray(option-BMC material)

 Surface Insulation Resistance

 106Ohm < black <109Ohm UV Protection

 Optional at request

 Earth Plate

 Sheet Molding Compound (SMC)
