Design Specification

 BS 6121, IEC 62444, EN/IEC 60529

 Compliance Standard

 IEC/EN 60079-0, 1, 7, 31

 ATEX Certification

 Presafe 16 ATEX 9168X

 IECEX Certification

 IECEx PRE 16.0093X

 TR CU Certification

 RU C-KR.AA87.B.01239/23(RUS)

 RU C-KR.AA87.B.01239/23(ENG)

 PESO Certification

 P465223

 INMETRO Certification

 DNV 21.0145 X

 CCC Certification

 2023012313592968

 Code of Protection

 II2G Ex db IIC Gb / Ex eb IIC Gb / II2D Ex tb IIIC Db

 Operating Temperature

 -20˚C ~ 110˚C

 Ingress Protection

 IP 66 / 67

 Gland Material

 Nickel Plated Brass(Standard),

 Brass(Only), Stainless Steel(316L)

 Gasket (washer)

 Nylon(Standard), PTFE-Teflon(Option)

 Accessories (optional)

 Lock Nut, Sealing Washer
