Design Specification

 BS 6121, IEC 62444, EN 50262

 Compliance Standard

 IEC/EN 60079-0, 1, 7,31

 ATEX Certification

 Presafe 17 ATEX 11454X

 IECEX Certification

 IECEx PRE 17.0062X

 KCS Certification

 18-KA2BO-0364~71X(KOR),

 18-KA2BO-0364~71X(ENG)

 TR CU Certification

 RU C-KR.AA87.B.01105

 Code of Protection

 II2G Ex db IIC Gb, Ex eb IIC Gb, II2D Ex tb IIC Db

 Operating Temperature

  -60°C -110°C

 Regulation

 Zone 1, 2, 21822, Gas Group IIA, IIB and IIC, Dust Group IIA, IIB and IIC

 Ingress Protection

 P66/67

 Applicable Cable Specification

 Braided armoured cable, unarmoured Cable

 Gland Material

 Nickel plated brass(standard), brass(only), Stainless steel(316L)

 Gasket (washer)

 Nylon(Standard), PTFE-Teflon(Option)

 Packing

 Silicone

 Accessories (optional)

 Secling Washer, lock nut, Earth Tag, Shroud, Serrated Washer
