Design Specification

 BS 6121, IEC 62444, EN 50262

 Compliance Standard

 IEC/EN 60079-0, 1, 7, 31

 ATEX Certification

 Presafe 17 ATEX 11454X

 IECEX Certification

 IECEx PRE 17.0062X

 KCS Certification

 18-KA2BO-0364~71X(KOR),

 18-KA2BO-0364~71X(ENG)

 TR CU Certification

 RU C-KR.AA87.B.01105

 Code of Protection

 II2G Ex db IIC Gb, Ex eb IIC Gb,II2D Ex tb IIIC Db

 Operating Temperature

 -60˚C ~ 110˚C

 Regulation

 Zone 1 & 2, Gas Group IIA, IIB and IIC, Dust Group IIIA, IIIB and IIIC

 Ingress Protection

 IP 66 / 67

 IP 68 available when requested only

 Applicable Cable Specification

 Non-armoured cable, Braided armoured cable

 Thread Available

 Male and Female type

 Male and Male type

 Female and Female type

 Gland Material

 Nickel plated brass(standard), Brass(only), Stainless steel(316L)

 Flexible Material

 Stainless steel(304, 316L)

 Gasket (washer)

 Nylon(Standard), PTFE-Teflon(Option)

 Packing

 Silicone

 Accessories (optional)

 Lock nut, Sealing washer, Earth tag, Serrated washer
