Design Specification

 DIN Thread (DIN 40430), ISO Metric Thread

 Ingress Protection

 IP 66/67

 Applicable Cable Specification

 Non-armoured cable

 Gland Material

 Nickel Plated Brass(Standard), Brass(Only)

 Gasket (washer)

 NBR, Nylon

 Packing

 NBR

 Accessories (optional)

 O-ring, Lock nut, Sealing washer
