OSBDBreather DrainBASICSPECIFICATION
Application : Breather Drains
· Provides draining water from an enclosure and breathing air out for ventilation
Design Specification
BS 6121, IEC 62444, EN/IEC 60529
Compliance Standard
IEC/EN 60079-0, 7, 31
ATEX Certification
IECEX Certification
KCS Certification
TR CU Certification
Operating Temperature
-60℃~110℃
Ingress Protection
IP 66
Gland Material
Nickel Plated Brass(Standard), Brass(Only),
Stainless Steel(316L)
Gasket (washer)
PTFE(Teflon)
Filter
Copper compressed metallic sinter
Accessories (optional)
Lock Nut, Sealing Washer
· The standard applied to KCS is Korean industrial standard created by translating IEC international standards without changing the technical content and standard format.
