Design Specification

 BS 6121, IEC 62444, EN 50262

 Ingress Protection (Metric)

 IP 66 / 68 (request in advance if IP68 required)

 Ingress Protection (NPT)

 NPT tapered hole : IP66,  IP68(apply non-hardening grease)

 Clearance hole : IP66/68(using IP Washer)

 Applicable Cable Specification

 All types of armoured cable

 Gland Material

 Nickel plated brass(standard), Brass(only), Stainless steel(316L)

 Gasket (washer)

 Nylon(Standard), PTFE-Teflon(Option)

 Packing

 Silicone

 Accessories (optional)

 Lock nut, Sealing washer, Earth tag, Shroud, Serrated washer
