Design Specification

 BS 6121, IEC 62444, EN 50262

 Compliance Standard

 EC/EN 60079-0, 1, 7,31

 ATEX Certification

 Presafe 17 ATEX 11456X

 IECEX Certification

 IECEx PRE 17,0063X

 KCS Certification

 18-KA2BO-0212~19X,0236~39X(KOR),

 18-KA2BO-0212~19X,0236~39X(ENG)

 TR CU Certification

 RU C-KR.AA87.B.01105

 Code of Protection

 12G Ex db IIC Gb, Exeblic Gb, 12D Ex tblic Db

 Operating Temperature

  -60°C -110°C

 Regulation

 Zone 1, 2, 21822, Gas Group IA, IB and IC

 Ingress Protection

 IP 66 / 67

 IP 68 available when requested only

 Applicable Cable Specification

 All types of armoured cable

 Gland Material

 Nickel plated brass(standard), Brass(only), Stainless steel(316L)

 Gasket (washer)

 Nylon(Standard), PTFE-Teflon(Option)

 Packing

 Silicone

 Accessories (optional)

 Lock nut, Sealing washer, Earth tag, Shroud, Serrated washer
